Running split DNS at home with dnsmasq

I run several services on my home network. Traefik routes each hostname to the correct container, while Cloudflare Tunnel makes selected services available when I am away from home.

I want to use the same hostname in both places:

• at home, the hostname should resolve to the server’s private IP address;
• outside, public DNS should send the connection through Cloudflare.

This arrangement is called split DNS or split-horizon DNS. The DNS answer changes according to where the query originates:

Inside the LAN
Laptop → dnsmasq → private IP → Traefik → service

Outside the LAN
Client → public DNS → Cloudflare → tunnel → service

Local traffic takes the shortest path, while the public route continues to work without a second bookmark or hostname.

Install dnsmasq

dnsmasq is a lightweight DNS forwarder and cache that works comfortably on a Raspberry Pi.

On a Debian or Ubuntu-based server:

sudo apt update
sudo apt install dnsmasq

Before configuring it, find the interface that serves the LAN:

ip -br address

The examples below use wlan0. A wired server may use a name such as eth0 or enp2s0.

A compact configuration

Create a file such as:

/etc/dnsmasq.d/lan.conf

Here is one practical example with three different kinds of local DNS rule:

# Accept DNS requests from the LAN, but not through loopback
interface=wlan0
except-interface=lo
bind-dynamic

# Use only explicitly configured upstream resolvers
no-resolv
server=1.1.1.1
server=9.9.9.9

# Keep frequently used answers in memory
cache-size=10000

# 1. Public hostname that should use a private address inside the LAN
address=/git.example.com/192.168.1.10
local=/git.example.com/

# 2. Hostname that exists only on the home network
address=/photos.home.arpa/192.168.1.20
local=/photos.home.arpa/

# 3. Send an entire private zone to another DNS server
server=/lab.home.arpa/192.168.1.53

Replace the interface names, addresses, and domains with values from the network being configured. example.com is used here as a placeholder; a real split-DNS hostname should be under a domain you control. home.arpa is the special-use domain intended for names inside home networks.

What the important lines mean

Control where dnsmasq listens

interface=wlan0
except-interface=lo
bind-dynamic

interface=wlan0 accepts queries on the Wi-Fi LAN interface. More than one interface= line can be added if the resolver must serve multiple networks.

When interface= is used, dnsmasq normally includes loopback automatically. except-interface=lo overrides that behavior. It is useful when another local resolver owns port 53, but it also means software on the server cannot reach this dnsmasq instance through 127.0.0.1.

bind-dynamic binds to addresses on the selected interfaces and notices matching interfaces or addresses that appear later. It is particularly useful with dynamic Linux interfaces.

Choose the upstream resolvers

no-resolv
server=1.1.1.1
server=9.9.9.9

no-resolv prevents dnsmasq from reading upstream nameservers from /etc/resolv.conf. The server= lines become the complete upstream list for ordinary internet queries.

The second server is not necessarily a passive backup. By default, dnsmasq observes which upstream servers respond well and chooses between them. strict-order can force the listed order, although most home networks do not need it.

Never configure an upstream router to forward back to the same dnsmasq instance. That creates a DNS loop.

Cache answers

cache-size=10000

dnsmasq caches frequently requested answers in memory, reducing repeated upstream lookups. It still respects DNS expiry rules; increasing the cache does not make records permanent.

Override a hostname locally

address=/git.example.com/192.168.1.10
local=/git.example.com/

address= returns the chosen private IP address. Inside the LAN, git.example.com now reaches the local reverse proxy. Outside the LAN, public DNS remains unchanged and can return a Cloudflare address.

The companion local= rule prevents other record types for this hostname from being forwarded upstream. This is important for IPv6 and is easy to miss.

Create a LAN-only name

address=/photos.home.arpa/192.168.1.20
local=/photos.home.arpa/

This follows the same pattern, but the name is intended only for the home network. The local= rule ensures that unanswered record types do not leave the LAN.

Delegate a private zone

server=/lab.home.arpa/192.168.1.53

This form of server= is domain-specific. Queries for lab.home.arpa and its subdomains go to 192.168.1.53; unrelated queries continue to use the ordinary upstream resolvers.

Why address= and local= belong together

My first split-DNS rule appeared to work because an A-record test returned the correct private IPv4 address. Browsers were less consistent: one reached Traefik locally, while another sometimes reached Cloudflare and displayed its public certificate.

The certificate was a symptom, not the cause.

Since dnsmasq 2.86, an IPv4 address= rule answers A queries locally, but queries for other record types can still be forwarded upstream. An AAAA query may therefore receive a public IPv6 address. A browser can prefer that address and take the public route.

This rule is incomplete for an IPv4-only local service:

address=/git.example.com/192.168.1.10

This pair keeps all queries for the hostname local:

address=/git.example.com/192.168.1.10
local=/git.example.com/

The A query receives the private IPv4 address. The AAAA query receives no address unless a local IPv6 address is explicitly configured.

Validate and test

Check the syntax before restarting the service:

sudo dnsmasq --test
sudo systemctl restart dnsmasq
systemctl status dnsmasq --no-pager

From another device on the LAN, query dnsmasq directly:

dig +short @192.168.1.10 git.example.com A
dig +short @192.168.1.10 git.example.com AAAA
dig +short @192.168.1.10 example.org A

For the example configuration, the first query should return 192.168.1.10, the second should return no address, and the third should return an ordinary public answer.

When a reverse proxy terminates TLS, its certificate can be checked without relying on browser DNS or caches:

openssl s_client \
  -connect 192.168.1.10:443 \
  -servername git.example.com \
  </dev/null 2>/dev/null |
openssl x509 -noout -subject -issuer -ext subjectAltName

If this direct test shows the expected certificate but a browser shows the public provider’s certificate, inspect the remote IP address before changing Traefik. The browser may simply be reaching the public endpoint.

Make clients use the local resolver

A correct server configuration helps only when LAN devices actually query it. The router’s DHCP settings should advertise the dnsmasq address as the network’s DNS server.

Avoid advertising a public resolver as a secondary DNS server. Clients may use any resolver they receive rather than waiting for the first one to fail, making split DNS unpredictable.

IPv6 needs the same attention. Routers can advertise DNS servers through IPv6 Router Advertisement or DHCPv6. Those resolvers must also preserve the local DNS path.

A browser configured with a custom DNS-over-HTTPS provider can bypass the operating system’s resolver. On devices that need split DNS, use the system resolver or configure Secure DNS so that local names are not sent directly to a public provider.

After changing DNS settings on macOS, cached answers can be cleared with:

sudo dscacheutil -flushcache
sudo killall -HUP mDNSResponder

At home, the hostname should now resolve to the private address and connect directly to Traefik. Outside the network, public DNS and Cloudflare continue to provide the external route.

The most useful lesson from this setup is simple: when a browser presents an unexpected certificate, check which IP address it reached. DNS may have chosen a different path long before TLS entered the picture.
